High strength and good heat dissipation Hydraulic Pump Bellhousing with cooler for hydraulic system
Hydraulic Pump Bellhousing with coolers are being widely used in hydraulic systems. REIJAY has launched a new line of compact coolers. As a Hydraulic Pump Bellhousing manufacturer, REIJAY has introduced into its products cooler bell jars using prismatic standard cooling elements.
A brief introduction to the Hydraulic Pump Bellhousing with cooler:
1. For connecting IEC standard and NEMA standard motor and hydraulic pump
2. The motor shaft and the pump shaft are self-aligned, and the dimensions are manufactured in accordance with the VDMA24561 standard, which can be used with standard brackets for heavy loads
3. Aluminum alloy material, die-casting by medium pressure machine, light weight, dense internal structure, high strength, good heat dissipation
4. Circulating cooling, no need for additional air blowing equipment, compact structure, easy installation, and environmental protection
5. Test pressure: According to DIN50104 standard, the standard static pressure is 26bar, the maximum can reach 40bar; the working pressure: 16bar
6. Structural composition: die-cast aluminum alloy shell, cooling module, fan impeller with coupling
7. Optional built-in shock absorption
Date for the Hydraulic Pump Bellhousing with cooler:
Typeof bellhousing | E-Motor Frame size | Power [kW] | Shaftend Dxl [mm] | Footbracket | DI | D2 | D3 | D4 | d1 min | d1 min | d2 | d3 | L | L1 | F | G | G1 | H2 |
RC 400/204/... | 200 L | 30 | 55x110 | PTFS400 | 400 | 350 | 300 | 300 | 50 | 50 | 265 | 260 | 204 | 26 | 6 | 18 | M16 | 22 |
RC 400/228/... | (DF350) | 262 | (DF350) | 228 | ||||||||||||||
RC 400/256/... | 50 | 259 | 283 | 256 | ||||||||||||||
RC 450/234/... | 225 S | 37 | 60x140 | PTFS450 | 450 | 400 | 350 | 350 | 80 | (DV400) | 301 | (DV400) | 234 | 26 | 6 | 18 | M16 | 20 |
RC 450/262/... | 225 M | 45 | 80 | 297 | 362 | 262 | ||||||||||||
RC 450/285/... | (DF401) | 276 | (DF4O1) | 285 | ||||||||||||||
RC 450/315/... | 315 | |||||||||||||||||
RC 550/248/... | 250 M | 55 | 65x140 | PTS5500 | 550 | 500 | 450 | 450 | 80 | 362 | 248 | 26 | 6 | 18 | M16 | 20 | ||
RC 550/265/... | 280 S+M | 75-90 | 75x140 | 359 | 265 | |||||||||||||
RC 550/275/... | 276 | 275 | ||||||||||||||||
RC 550/295/... | 295 | |||||||||||||||||
RC 550/315/... | 315 | |||||||||||||||||
RC 660/310/... | 315 S+M+L | 110-132 | 80x170 | PTS660 | 660 | 600 | 550 | 550 | 80 | 414 | 310 | 32 | 6 | 23 | M20 | 20 | ||
RC 660/330/... | 160-200 | 276 | 330 | |||||||||||||||
RC 660/345/... | 345 | |||||||||||||||||
RC 800/315/..** | 355 L | 250-315 | 95x170 | 800 | 740 | 680 | 680 | 125 | 468 | 315 | 60 | 10 | 23 | M20 | 35 | |||
RC 800/335/..** | 400 L | 355-400 | 100x210 | 474 | 335 | |||||||||||||
RC 800/350/..** | 435 | 350 | ||||||||||||||||
RC 800/443/..** | 490 | 443 |
