Low pressure drop and high cooling efficiency RTC standard tubular oil-water coolers
1. Compact structure design (aluminum ally cooling fin combined with standard copper-nickel tube) High strengthen steel shell.
2. Stable drop pressure. Hiah cooling efficiency.
3. Test pressure: According to DIN standard, max hydraulic hose static pressure 40bar. Max working pressure 16bar( tested for 2 millions times in the reciprocating circulation test under the condition of 60℃.2Hz. 0-16 bar) Water circuit max working pressure 16bar and max temperature tolerance 95℃.
4. Max cooling power 500KW. Max fluid flow 850L/min.
5. We have one water channel, two water channels and four water channels as option, which applies for different water cooling reguirements.
6. Corrosive proof material for sea water application.
7. Industry water or sea water as the cooling water.
8. Length can be customized and max length can be 2200mm.
9. Easy for tube disassemble and cleaning. Flange on cover side can spin 0-90.
10 Main components: aluminum alloy shell/cooling block(cooling fin or cooling channel)/cover/seal/bracket.
11.0il filter precision 50u and water filter precision 0.5mm. Water PH6.
Welcom to contact us!
