Dentex Sae Flywheel Coupling Fl Pa Nylon Flanges For Combustion Engines

body materail STEEL
KEY WORDS DENTEX FL-PA nylon flanges for combustion engines
MODEL RJK200
Application construction machinery engine
certification ISO9001/ITS16949
OEM YES
Feature high transmission rate;high mechanical strength
Standard SAE Flywheel
warranty 2years

Request For Quotation

Description
Q & A
Customer Reviews
Shipping Policy
Wholesale Inquiry

Dentex Fl-Pa Nylon Flanges For Combustion Engines

CHINA OEM Manufacturer Bowex FL-PA nylon flanges for combustion engines KTR

SAE Standard flywheel parameter

size	bolt mounting center circke D1mm	outer diameter Dmm	bolt hole diameter mm	bolt hole quantity
7 _1/2"	200.02	215.90	9	6
7 _1/2"	222.25	241.30	9	8
8"	244.47	263.52	11	6
10"	295.27	314.32	11	8
11_1/2"	333.37	352.42	11	8
14"	438.15	466.72	14	8

size	bolt mounting center circke D1mm	outer diameter Dmm	bolt hole diameter quantity mm	location dimension
96	50	96	4x8	70
125	100	125	3x8	80
135	100	135	3x8	135
150	130	150	5x8	106
152	122	152	3x12	105
155	125	155	3x12	155
210	185	210	3x10	125
220	165	220	6x10	220
220	185	220	3x12	125
170	140	170	3x14	170
209	165/170	209	6x16/3x16	209

RB series FL flywheel coupling technical parameter

size	prebore (mm)		dimension (mm)							special length	SAE size						axial	radial	angular
size	min	max	B	D2	L1	L2	L3	L4	L5	L1max (mm)	6_1/2"	7_1/2"	8"	10"	11_1/2"	14" *	max offset (mm)
42	20	42	65	100	42	35	42	20	13	60	X	X	X	X			±1	±0.4	±1°
48	20	48	68	100	50	43	50	20	13	60	X	X	X	X				±0.4
65	25	65	96	132	55	49	55	27	21	70	—			X				±0.6
65	25	65	96	172	55	46	55	31	22	70	—				X			±0.6
80	30	80	124	172	55	46	55	30	21	90	—				X	X		±0.8
100	38	100	152	265	70	78	70	35	21	110	—	—	—	—	X	X

replace KTR Bowex FL-PA nylon flanges for combustion engines and Centaflex coupling. We are OEM manufacturer. So we can replace KTR and centaflex coupling completely whole set and we will creat drawing for you and guarantee long service life. you need to provide us below:

1.Description of the equipment[For example:Excavator(8 ton) JR978,Road machinery JR934,Mining machinery(90 ton) JR989,Agricultural machinery JR990,Marine machinery JR901...]

2.Brand,model(For example:CUMMINS 6BTAA5.9-C160...)Maximum output torque and Maximum output speed(For example:580NM,2200RPM...)Drawing of flywheel,Drawing of flywheel housing..If there is a connection board between the flywheel housing and the pump, please attach the drawings of the pump connection board

Are you trading company or manufacturer ?
A: We are global construction machinery OEM manufacturer and we have been Cat,Sany,Xcmg,Liugong,Zoomlion,Cummins,Yanmar,Deutz,Kubota,Rexroth,Parker....supplier for many years.
How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-60 days if the goods are not in stock, it is according to quantity.
How long should I wait for the reply after I send the inquiry?
A: Within 12 hours.
What infomation should I tell you to confirm the product?
A: Model/Size, Shaft diameter, hole diameter&Order quantity etc.
What is your product warrenty period?
A:We offer one year warrenty since the vessel departure date left China.
What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.We accept the LC also.
China OEM manufacturer Reijay replace KTR Bowex FL-PA nylon flanges for combustion engines and Centaflex coupling. If you have another question, pls feel free to contact us.
