Standard form Long service life Flexible Gear Coupling for shaft transmission system
There are hundreds of types of Flexible Gear Coupling, but there are two basic forms: 1. Combination of internal teeth and external teeth; 2. Combination of end teeth. All other forms are variations on these two foundations. The tooth clutch with internal teeth and external teeth has a relatively large transmission torque. Taking into account the different needs of users, it is intentionally designed so that the lengths of the shaft ends on both sides of the teeth are inconsistent, so that users can choose the installation direction according to their needs. So, there is no rule on which end faces where. Attention should be paid to the installation: 1. If it is replaced on the original equipment, it should generally be in the same direction as the original. If it is a newly designed and manufactured equipment, then it should be installed according to the inner and outer parts without interfering with other surrounding parts. The more tooth joint surfaces, the more reliable the principle of installation.
Technical data of Flexible Gear Coupling:
Size | rated torque Nm | max rotary speed | Bore size | weight FHD(FHDFR) KG |
OAL FHD(FHDFR) mm |
LTB mm | LTB1 mm | ||
Non dynamic balance RPM | dynamic balance RPM | ID1 | ID2 | ||||||
max | max | ||||||||
7 | 110000 | 2000 | 3000 | 225 | 320 | 431 (462) | 451 (452) | 221 | 221 |
8 | 150000 | 1900 | 2850 | 310 | 375 | 708 (730) | 568 (572) | 279 | 279 |
9 | 210000 | 1750 | 2625 | 340 | 415 | 915 (966) | 597 (598) | 292 | 292 |
10 | 280000 | 1550 | 2325 | 355 | 455 | 1,135 (1236) | 622 (626) | 305 | 305 |
11 | 390000 | 1400 | 2100 | 410 | 500 | 1,535(1653) | 679 (683) | 334 | 334 |
12 | 500000 | 1300 | 1950 | 435 | — | 1,891(2047) | 718 (721) | 353 | 353 |
13 | 600000 | 1150 | 1725 | 480 | — | 2,368(2542) | 762 (762) | 372 | 372 |
14 | 730000 | 1050 | 1575 | — | — | 2,906 (3104) | 806(806) | 394 | 394 |
15 | 880000 | 900 | 1350 | — | — | 3,500 (3743) | 857 (857) | 419 | 419 |
16 | 1070000 | 800 | 1200 | — | — | 4,200 (4471) | 908 (908) | 441 | 441 |
18 | 1420000 | 550 | 825 | — | — | 5,398 (5754) | 940(940) | 457 | 457 |
20 | 1920000 | 450 | 675 | — | — | 7,641 (8223) | 1099 (1099) | 537 | 537 |
22 | 2420000 | 380 | 570 | — | — | 9,974 (10747) | 1194(1197) | 584 | 584 |
24 | 2990000 | 325 | 485 | — | — | 12,592(13601) | 1283(1286) | 629 | 629 |
26 | 3700000 | 280 | 420 | — | — | 15,604(16845) | 1372 (13750 | 673 | 673 |
28 | 4410000 | 240 | 360 | — | — | 18,573(19981) | 1403(1407) | 689 | 689 |
30 | 5340000 | 220 | 330 | — | — | 21,551 (23184) | 1429(1432) | 702 | 702 |
